Standard voltage:
1.2VCharging current:
0.2C5AFeature:
1). Large range of working temperature
2). Strong structure
3). Low rate of self discharge
Application:
1).Alarms
2).UPS
3). Telecommunications
4). Railway signaling
Constant Current Discharge Characteristics (A, 20℃)
F.V/TIME | 8h | 5h | 3h | 2h | 1h | 30min | 20min | 15min | 10min | 5min | 1min |
1.0V | 126 | 200 | 310 | 420 | 650 | 800 | 850 | 900 | 1000 | 1100 | 1220 |
1.05V | 125 | 194 | 280 | 400 | 600 | 650 | 700 | 800 | 850 | 1000 | 1200 |
1.1V | 125 | 190 | 270 | 350 | 460 | 550 | 600 | 650 | 700 | 800 | 1050 |
1.14V | 118 | 180 | 250 | 280 | 380 | 450 | 500 | 550 | 600 | 650 | 850 |
Storage of the battery：
1).Long-time storage
If the battery is stored for a long time, it is advisable to spill out the electrolyte and screw the vent plug tightly at once after normal discharge, then clean it. If there is a hole on the vent plug, seal it with medical glue. Coat the metal parts with vaseline oil and store them in a dry, acidless, and well-ventilated room .
