Standard voltage:
1.2VCharging current:
0.2C5AFeature:
1). Good performance of discharge
2). Strong resistance to overcharge/over discharge
3). Large range of working temperature
Application:
1).Alarms
2).UPS
Filling with the electrolyte：
Unscrew the vent plug, fill the electrolyte into the battery in time(electrolyte standard and preparation method is shown in Appendix 1.) Adjust electrolyte level between two limit lines. Screw the vent plug again, move the sealer on the hole of the vent plug and clean the battery. The battery must be soaked for 4 hours after filling with electrolyte then adjust electrolyte level again
Dimensions：
specification：
Nominal Voltage | 1.2V | ||
Capacity(5HR,20℃) | 100Ah | ||
Dimension | Length | 139±2mm | |
Width | 79±2mm | ||
Total Height | 295±5mm | ||
Approx. Weight | 6.0Kg | ||
Internal resistance (Fully charged, 20℃) | Approx.0.0025 Ω | ||
Capacity affected by temperature (5HR) | 20℃ | ≥100％ | |
-18℃ | ≥80％ | ||
Self-discharge(20℃) | 3 month | ＜30％ | |
Nominal operating temperature | 20℃±5℃ | ||
Operating temperature range | –20℃～50℃ | ||
Float charging voltage(20℃) | 1.44 ～1.50V | ||
Maximum charging current | 20A | ||
Boost charge (20℃) | 1.65-1.70V | ||
Terminal material | Nickel- Clad Steel | ||
Container | PP/ABS | ||
GN(KPL) TYPE DISCHARGE CURVE(（20±5℃）：
Constant Current Discharge Characteristics (A, 20℃)
F.V/TIME | 8h | 5h | 3h | 2h | 1h | 30min | 20min | 15min | 10min | 5min | 1min |
1.0V | 13 | 20 | 32 | 43 | 66 | 81 | 86 | 91 | 103 | 112 | 124 |
1.05V | 12.7 | 19.5 | 28.5 | 41 | 61 | 67 | 72 | 83 | 86 | 103 | 122 |
1.10V | 12.5 | 19.2 | 28 | 36 | 47 | 56 | 62 | 67 | 73 | 82 | 107 |
1.14V | 12 | 18 | 25.5 | 29 | 38.7 | 46 | 52 | 57 | 62 | 67 | 88 |
